Introduction
★ Regarding lifting weight description in the above table
1) Value shown in the table is max.lifting weight when crane works on o flat,solid surface.Also lifting weight is less than 75% of tipping load.
2) The lifting weight include hook and suspenders in the table;
3) Actual value of working radius is include deformation of booms,so it must work based on working radius.
4) 75% tipping load considers strong breeze, crane can still work with openning the outriggers when air pressure is 125N/m2 ,but it forbids working without outriggers and traveling working with load.
in any direction.
Outline drawing
