1-4 Ton Small Self Erecting Tower Cranes

XJCM brand small tower crane 1 ton to 4 ton feature is no need working on the high level during erecting and dismounting. No require professional operator, operating simply, mastering easily.
  • Fast And Safe Logistics

  • Get samples for free

Introduction

The 1-4 ton small self-erecting tower crane is a tool designed for easy transportation and installation. It usually has a small footprint and can be installed quickly. No separate crane is required for assembly.

1-4 ton self-erecting tower cranes are ideal for small construction projects. Or for tight spaces where large cranes are not practical. It can lift up to 4 tons (8,000 lbs) at a time. Suitable for various tasks. Examples include lifting construction materials, equipment, and tools.

One advantage of a self-erecting tower crane is that it can be easily transported from one job site to another. It can be transported to the next location in a flatbed truck or trailer. Once at the site, it can be set up quickly and easily by a trained operator.

Self-erecting tower cranes have another advantage. Simply because it takes up less space on the job site than a traditional tower crane. This can be particularly useful in urban areas where space is at a premium.

Overall, a 1-4 ton self-erecting tower crane is a versatile and practical tool for small construction projects and tight spaces.

1-4 Ton Small Self Erecting Tower Cranes feature:

1-4 tons small self-erecting tower crane FAQ

Q: What is a self-erecting tower crane?

A:A self-erecting tower crane is a type of crane. It is designed for easy transport and installation on the job site. It usually has a small footprint and can be installed quickly. No separate crane is required for assembly.

Q: What is the lifting capacity of a 1-4 ton small self-erecting tower crane?

A:T tower crane would typically be able to lift loads up to 4 tons at a time.

Q: What are some of the advantages of a self-erecting tower crane?

A: Self-erecting tower cranes are designed to be easily transported and set up on a job site. They put little strain on the environment and can be installed in a matter of days. They’re also ideal for use in small spaces, tight corners and smaller workplaces. They are also designed to be operated by one person, with controls that are easy to use.

Q: What kind of construction tasks can a 1-4 ton small self-erecting tower crane be used for?

A: Self-erecting tower cranes can be used to perform a range of tasks. From lifting construction materials to positioning equipment and tools. They are perfect for small construction projects or for use in tight spaces where a larger crane would not fit.

Q: Are self-erecting tower cranes safe to use?

A: Yes, self-erecting tower cranes are equipped with a range of safety features. Such as overload protection and emergency stop buttons to keep construction workers safe. It is important to ensure that the crane is operated by a well-trained and experienced operator. To ensure safe and efficient use.

Specifications

JFYT1720-10 Tower crane main technology specification

Category

Item

Unit

Parameter

Dimension

Overall length

mm

10260

Overall width

mm

2210

Overall height

mm

3040

Axle base

mm

5260

Front tread

mm

680

Rear tread

mm

1870

Weight

Dead weight in travel state

Kg

11420

Axle load Front axle

Kg

5200

Rear axle

Kg

6220

Drive

Travel speed Max. travel speed

Km/h

15

Turning radius Min. turning radius

m

13

Min. ground clearance

mm

230

Outrigger span in working state

m

3.5*3.5

Swing radius at turntable tail

m

2.52

 JFYT1720-10 Tower crane main performance parameters

Mechanism operation Lifting mechanism M5
Swing mechanism M4
Hauling mechanism M4
Lifting height (m) Rate Max height
α=2 17
Max. hoisting weight (t) 1
Radius (m) Max. radius (m) 20
Min. radius (m) 5
Lifting mechanism Rate α=2
Hoisting weight (t) 1
Speed (m/min.) 12
Swing mechanism Speed (rpm)
0.6
Luffing mechanism Speed (m/min.)
17
Erecting mechanism Erecting time (min) Folding time (min)
6 6
Hydraulic system working pressure (MPa) Oil tank capacity (L)
28 140
Total power 13.9KW
