| Max.hoistingheight:16m |
| Max.workingradius: 18m |
| Max.hoistingweight: 1,000kg |
Fast And Safe Logistics
Get samples for free
1) Compact Design: The self-erecting mechanism allows the crane to be quickly set up in confined spaces, ideal for urban and restricted job sites.
2) Lightweight and Portable: Easy to transport and assemble, reducing logistical challenges and setup time.
3) Flexible Rotation: 360-degree slewing capability provides precise load positioning for efficient workflow.
4) Remote Control Operation: Offers improved safety and convenience by allowing operators to manage the crane from a distance.
5) Energy Efficient: Equipped with modern electrical systems to reduce energy consumption without compromising performance.
1) Ease of Assembly: The self-erecting feature minimizes manual labor and setup time, leading to faster project starts.
2) Cost-Effective: Its compact size and reduced setup costs make it a budget-friendly option for smaller projects.
3) Versatile Usage: Can handle a variety of lifting tasks, from materials to equipment, with precision and safety.
4) Enhanced Safety: Modern safety systems, including overload protection and stable base design, ensure reliable operation.
5) Space-Saving: Perfect for projects with limited space, such as residential construction or urban infrastructure.


1)Residential Construction: Ideal for small building projects, such as single-family homes or low-rise apartments.
2) Urban Infrastructure: Suitable for projects in crowded urban areas where space is limited.
3)Renovation Work: Efficient for lifting materials and equipment in building renovations or remodeling.
4) Light Industrial Use: Supports small-scale industrial assembly lines or storage yards.
| Project | unit | JFYT1720-10 |
| Dimensions | mm | 10400*2200*3040 |
| Maximum Lifting Height | m | 16 |
| Maximum Working Radius | m | 18 |
| Maximum Lifting Capacity | Kg | 1000 |
| Maximum Working Radius At Rated Max. Lifting Capacity |
m | 10 |
| Lifting Capacity At Maximum Working Radius |
Kg | 500 |
| Erection Time | min | 6 |
| Outrigger Span | m | 3.5X3.5 |
| Hydraulic System Working Pressure | Mpa | 28 |
| Maximum Towing Speed | Km/h | 15 |
| Power Supply | 380V/50Hz | |
| Total Power | KW | 11.4 |
| Total Weight (Transport Weight) | Kg | 14500Kg |
| Max. Operating Weight (Incl. Rated Load) |
Kg | 15500Kg |
| Features | Delixi or Chint Electric, wireless remote control operation, jiufa force limiter, fully automatic erection |
